隨著互聯網技術與應用的快速發展，云計算，云存儲，大數據等相關新型互聯網業務規模與日俱增，數據中心進入規模化建設階段。數據中心巨大規模的建設與應用，導致數據中心對供電需求快速增長，根據ICT Research 機構預測，2016年的中國數據中心耗電量已逾1000億千瓦時，相當于三峽水電站年發電總量。于此同時，全球數據中心用電量也已超過10000億千瓦時。據美國媒體調查，全球各大網站僅數據中心的用電功率，就相當于30個核電站的供電功率，巨大的用電容量給數據中心的建設和運營都帶來了全新的挑戰。
With the rapid development of Internet technology and application, the scale of cloud computing, cloud storage, big data and other related new Internet business is increasing day by day, and the data center has entered the stage of large-scale construction. The huge scale construction and application of the data center has led to the rapid growth of the power supply demand of the data center. According to the forecast of ICT research organization, the power consumption of China's data center in 2016 has exceeded 100 billion kwh, equivalent to the total annual power generation of the Three Gorges Hydropower Station. At the same time, global data center power consumption has exceeded 100 billion kwh. According to the US media survey, the power consumption of the data center of the world's major websites is equivalent to that of 30 nuclear power plants. The huge power consumption capacity has brought new challenges to the construction and operation of the data center.
目前在數據中心運營過程中，由于電力故障，設備故障，雷擊事件等導致的數據中心用電安全事故時有發生。事實上，數據中心的用電故障帶來的損失不僅僅是數百上千萬美元的直接經濟損失，對于眾多國際知名品牌與上市公司來說，品牌和股價等隱形價值的負面影響難以估量。
At present, in the process of data center operation, due to power failure, equipment failure, lightning events, etc., data center power safety accidents occur from time to time. In fact, the power failure of the data center will not only cause direct economic losses of tens of millions of dollars, but also the negative impact of invisible values such as brand and stock price for many international famous brands and listed companies.
隨著新型功率半導體器件的發展，新型電力電子電能變化拓?fù)涞陌l(fā)明與應用，以及現代控制理論與數字控制技術的發展，數據中心不間斷供電技術得到了顯著的提升，對供電系統的可靠性，成本與技能，配置靈活性和可擴展性等提供了有效的技術支撐。
With the development of new power semiconductor devices, the invention and application of new power electronic power change topology, and the development of modern control theory and digital control technology, uninterrupted power supply technology in data center has been significantly improved, which provides effective technical support for the reliability, cost and skills, configuration flexibility and scalability of power supply system.
大型數據中心供電的任何故障都可能給業主和客戶帶來重大的經濟損失或者災難性的后果。因此，數據中心能否可靠運營的關鍵之一是IT設備的不間斷供電。在保證不間斷供電的前提下，不斷提升不間斷供電架構的可靠性，是數據中心用戶一直以來的核心需求。
Any failure of power supply in large data center may bring great economic loss or disastrous consequences to owners and customers. Therefore, one of the keys to the reliable operation of data center is the uninterrupted power supply of IT equipment. On the premise of ensuring uninterrupted power supply, improving the reliability of uninterrupted power supply architecture is always the core demand of data center users.
通常數據中心不間斷供電系統一般包括高壓配電系統，變壓器，柴油發電機組，低壓配電系統，防雷器，UPS，電池組，列頭柜，機架分配單元（PDU），連接器等組成環節。其中UPS作為不間斷供電系統的核心部件，起到舉足輕重的作用。為了使不間斷供電系統始終保持高效的運作，在特定環境下，選擇雙轉換在線式可能更為合適。特別是在 AC 電源高度失真和/或具有極大電壓變化的地理區域，雙轉換在線式 UPS 無需頻繁轉換到電池供電即可維持正常輸出。較低的電池使用率可以保存電池容量以應對長時間的斷電事故，并延長電池使用壽命。此外，降低電池更換成本可以抵消在線互動式 UPS 低初始成本和低運營成本的優勢。在某些特殊的情況下可能需要使用雙轉換在線式 UPS，比如對于某些醫療設備或儀器，需要進行功率因數校正(PFC)、要求較小的物理尺寸或需要進行頻率轉換等等。前文提到的高效包括：
Generally, uninterrupted power supply system of data center generally includes high-voltage distribution system, transformer, diesel generator set, low-voltage distribution system, lightning arrester, UPS, battery pack, column cabinet, rack distribution unit (PDU), connector and other components. UPS, as the core component of uninterrupted power supply system, plays an important role. In order to keep the uninterrupted power supply system operating efficiently, it may be more appropriate to choose the double conversion on-line mode in a specific environment. Especially in geographic areas where AC power supply is highly distorted and / or has great voltage variation, dual conversion On-line UPS can maintain normal output without frequent switching to battery power supply. Low battery utilization can save battery capacity to cope with long-term power failure and prolong battery life. In addition, reducing the cost of battery replacement can offset the advantages of low initial cost and low operating cost of Online Interactive UPS. In some special cases, double conversion On-line UPS may be used, such as power factor correction (PFC), smaller physical size or frequency conversion, etc. for some medical devices or instruments. The efficiency mentioned above includes:
2 轉換效率高(Po/Pin>96%)
2. High conversion efficiency (PO / pin > 96%)
2 輸入電流波形的正弦波畸變率?。?lt;5%）
The sine wave distortion rate of 2 input current waveform is small (< 5%)
2 優異的動態負載跟隨相應
2 excellent dynamic load follow corresponding
2 N+X的冗余工作模式
Redundancy mode of 2 N + X
為使UPS工作在上述的高效模式，這其中離不開電量傳感器對一些關鍵位置的電壓和電流信息的量測。
In order to make ups work in the above-mentioned high-efficiency mode, it is necessary to measure the voltage and current information of some key positions by the power sensor.
